Mitsubishi MELDAS HS Series User Manual

Chapter 4 Option and Peripheral Devices
4–17
(2) Selection from input current
Use the following table to select the contactors so the total input current for each unit does not
exceed the rated continuity current.
Input current table
Intelligent servomotor
MDS-B-SVJ2 total output
capacity
1.5kW or less 3.5kW or less 7kW or less 10kW or less 13kW or less 16kW or less
Input current 10A 20A 30A 40A 50A 60A
MDS-B-SPJ2
MDS-B-SPJ2-02
MDS-B-SPJ2-04
MDS-B-SPJ2-075
MDS-B-SPJ2-15
MDS-B-SPJ2-22
MDS-B-SPJ2-37
MDS-B-SPJ2-55 MDS-B-SPJ2-75 MDS-B-SPJ2-110
Input current 10A 20A 30A 40A 50A
Converter unit
MDS-A-CR-10
MDS-A-CR-15
MDS-A/B-CV-37
MDS-A-CR-22
MDS-A-CR-37
MDS-A/B-CV-55
MDS-A-CR-55
MDS-A/B-CV-75
MDS-A-CR-75
MDS-A-CR-90
MDS-A/B-CV-110
Input current 10A 20A 30A 40A 50A
Contactor selection table 2
Contactor rated continuity
current
(Total input current)
20A 32A 50A 60A
Recommended contactor
(Mitsubishi Electric Corp.:
Option part)
S-N10
AC200V
S-N20
AC200V
S-N25
AC200V
S-N35
AC200V
Special order part: This part is not handled by the NC Dept. Marketing Section or dealer.
The contactor is selected for the MDS-B-SVJ2-10 with four HS-SF102 axes and one
MDS-B-CV-55 connected.
< Selection from rush current >
(HS-SF102 × 4 axes rush current) + (MDS-B-CV-55 rush current) = 4 × 100A + 15A
= 415A
Therefore, S-K50 200VAC.
< Selection from input current >
(JS-SF102 × 4 axes input current) + (MDS-B-CV-55 input current) = 30A + 30A = 60A
Therefore, S-N35 200VAC.
From these, the S-K50 200VAC is selected as having the larger of the two capacities.
4-2-4 Circuit protector
When installing a circuit protector dedicated for the control power input, use a circuit protector with
inertial delay to prevent malfunctioning in respect to the rush current generated when the power is
turned ON. The size and conductivity time of the rush current fluctuate according to the power supply
impedance and potential.
Servo amplifier Rush current
Conductivity
time
Recommended circuit
protector
(Mitsubishi Electric
Corp.: Option part)
CP30-BA type with
medium-speed inertial delay
Intelligent servomotor 70 to 130A 0.5 to 1msec Rated current 0.2A per axis
Special order part: This part is not handled by the NC
Department Marketing Section or dealer.
(Example 2)
