10 - 8
MELSEC-Q
10 HIGH-LEVEL POSITIONING CONTROL
10.3.2 Block start (normal start)
In a "block start (normal start)", the positioning data groups of a block are continuously
executed in a set sequence starting from the positioning data set in "
Da.12
Start data
No." by one start.
Section [2] shows a control example where the " block start data" and "positioning
data" are set as shown in section [1].
[1] Setting examples
(1) Block start data setting example
Da.11 Da.12 Da.13 Da.14
Axis 1 block
start data
Shape Start data No.
Special start
instruction
Parameter
1st point 1: Continue 1 0: Block start –
2nd point 1: Continue 2 0: Block start –
3rd point 1: Continue 5 0: Block start –
4th point 1: Continue 10 0: Block start –
5th point 0: Termination 15 0: Block start –
•
•
(2) Positioning data setting example
Da.1 Axis 1 position-
ing data No.
Operation pattern
1 00: Termination
2 11: Continuous path control
3 01: Continuous positioning control
4 00: Termination
5 11: Continuous path control
6 00: Termination
1 block
1 block
•
10 00: Termination
•
15 00: Termination
•
REMARK
Block :
"1 block" is defined as all the data continuing from the positioning data in which
"continuous positioning control" or "continuous path control" is set in the operation
pattern (
Da.1
) to the positioning data in which "independent positioning control
(positioning termination)" is set.
