3 - 16
MELSEC-Q
3 SPECIFICATIONS AND FUNCTIONS
3.4 Specifications of interfaces with ex
ternal
devic
es
3.4.1 Electrical
specifications of input signal
s
Input specif
ications
Signal name
Rated input
voltage/current
W
orking
voltage range
ON
voltage/current
OFF
voltage/current
Input
resistance
Response
time
Stop signal (STOP)
Upper limit signal
(FLS)
Lower limit signal
(RLS)
24VDC/5mA
19.2 to
26.4VDC
17.5VDC or more/
3.5mA or more
7VDC or less/
1.0mA or less
Approx. 6.8k
Ω
4ms or less
5VDC/5mA
4.5 to 6.1VDC
2.5VDC or more/
1mA or more
1VDC or less/
0.1mA or less
Approx. 1.2k
Ω
1ms or less
1
Pulse width
2ms or more
1ms or mo
re
1ms
or more
(Duty
ratio:
50%)
2
Phase difference
Manual pulse
generator A phase
(PULSE
GENERATOR A)
Manual pulse
generator B phase
(PULSE
GENERATOR B)
A
phase
B ph
ase
0.5ms or more
W
hen the A phase leads the B phase, the
positioning address (current value) increases.
Near-point dog signal
(DOG)
External command
signal (CHG)
24VDC/5mA
19.2 to
26.4VDC
17.5VDC or more/
3.5mA or more
7VDC or less/
1.0mA or less
Approx. 6.8k
Ω
1ms or less
66
68
