9 - 81
MELSEC-Q
9 MAJOR POSITIONING CONTROL
9.2.15 4-axis speed control
In "4-axis speed control" ("
Da.2
Control system" = Forward run: speed 4, Reverse
run: speed 4), control is carried out in the 4-axis direction in which the positioning data
has been set by continuously outputting pulses for the speed set in "
Da.8
Command
speed" until the input of a stop command.
The two types of 4-axis speed control are "Forward run: speed 4" in which the control
starts in the forward run direction, and "Reverse run: speed 4" in which control starts in
the reverse run direction.
(Refer to Section 9.1.6 "Interpolation control" for the combination of the reference axis
with the interpolation axes.)
To Next Page
