Mitsubishi QD75P1N User Manual

12 - 2
MELSEC-Q
12 CONTROL SUB FUNCTIONS
12.1 Outline of sub functions
"Sub functions" are functions that compensate, limit, add functions, etc., to the control
when the main functions are executed. These sub functions are executed by
parameter settings, commands from GX Configurator-QP, sub function sequence
programs, etc.
12.1.1 Outline of sub functions
The following table shows the types of sub functions available.
Sub function Details
OPR retry function
This function retries the machine OPR with the upper/lower limit switches
during machine OPR. This allows machine OPR to be carried out even if the
axis is not returned to before the near-point dog with JOG operation, etc.
Sub functions
specifically for
machine OPR
OP shift function
After returning to the machine OP, this function offsets the position by the
designated distance from the machine OP position and sets that position as
the OP address.
Backlash compensation
function
This function compensates the mechanical backlash. Feed pulses equivalent
to the set backlash amount are output each time the movement direction
changes.
Electronic gear function
By setting the movement amount per pulse, this function can freely change
the machine movement amount per commanded pulse.
A flexible positioning system that matches the machine system can be
structured with this function.
Near pass function 1
This function suppresses the machine vibration when the positioning data is
switched during continuous path control in the interpolation control.
Functions for
compensating
the control
Output timing selection of
near pass control
This function allows the user to select the timing to output the difference
(
) between the actual and the set positioning end addresses in
continuous path control, in which the difference (
) is output during the
execution of the next positioning data.
Speed limit function
If the command speed exceeds "
Pr.8
Speed limit value" during control,
this function limits the commanded speed to within the "
Pr.8
Speed limit
value" setting range.
Torque limit function 2
If the torque generated by the servomotor exceeds "
Pr.17
Torque limit
setting value" during control, this function limits the generated torque to
within the "
Pr.17
Torque limit setting value" setting range.
Software stroke limit
function
If a command outside of the upper/lower limit stroke limit setting range, set in
the parameters, is issued, this function will not execute positioning for that
command.
Functions to
limit the control
Hardware stroke limit
function
This function carries out deceleration stop with the limit switch connected to
the QD75 external device connector.
Speed change function
This function changes the speed during positioning.
Set the changed speed in the speed change buffer memory (
Cd.14
New
speed value), and change the speed with the speed change request
(
Cd.15
Speed change request).
Override function
This function changes the speed within a percentage of 1 to 300% during
positioning. This is executed using "
Cd.13
Positioning operation speed
override".
Acceleration/deceleration
time change function
This function changes the acceleration/deceleration time during speed
change. (function added to the speed change function and override function)
Torque change function This function changes the "torque limit value" during control.
Functions to
change the
control details
Target position change
function
This function changes the target position during the execution of positioning.
At the same time, this also can change the speed.
