Use VLANS for Traffic Segmentation
45
ProSAFE 8-Port and 16-Port Gigabit Click Switch
9. For each port to be configured, enter the VLAN group ID (1–409344 or all).
10. Click the Apply button.
Your settings are saved.
Add Advanced 802.1Q VLAN Groups
You configure ports to a VLAN group ID (1–4093 or all). The advanced configuration feature
allows you to create and update VLAN groups with more information.
Use the ProSAFE Plus Utility to Add Advanced 802.1Q VLAN
Groups
To add advanced 802.1Q VLAN groups:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection.
2. Double-click the ProSAFE Plus Utility icon.
The configuration home screen displays a list of Plus switches that it discovers on the
local network.
3. Select a switch.
If you do not see the switch, click the REFRESH button.
4. Click the APPLY button.
You are asked to enter the password for the switch.
5. Enter the switch’s password in the password field.
The switch’s default password is password.
The Switch Status screen displays.
6. Select VLAN > 802.1Q > Advanced.
The Advanced 802.1Q VLAN screen displays a list of the currently defined VLANS and
the ports assigned to each.
7. In the VLAN ID field, enter the VLAN ID (1-4093) for the VLAN you want to configure and
click the Add button. The new VLAN group is displayed in the VLAN ID column.
8. Use VLAN membership to add ports to the group.
Note: To delete a VLAN group, select the check boxes for the VLAN and
click the Delete button.
