Nikon D60 Repair Manual

- Ｄ  ･ -
logo_Q0650_forGraphic
071004_Gdesign_ito
VBA21001-R.3753.A
Points to notice for Disassembly / Assembly
㧍
内部に高電圧部あり。カバーを外す時は感電に注意すること。
カバーを外した後は、修理指針の指示に従ってメインコンデン
サーの放電を必ず行うこと。
警告
Caution:
Whenever "Separation of Front and rear bodies", "Disassembly of CCD/FPC unit", or
"Disassembly of Bayonet" are performed, be sure to perform "RESET AF-DEFOCUS
COMPENSATION" of camera adjustment software after reassembling.
WARNING
Due to an internal high voltage area,
take extra care not to get
an electric shock when detaching covers.
After removing covers, b
e
sure to discharge the main
condenser according to the instructions of repair manuals
.
Note:
①
When disassembling/(re)assembling, be sure to use the conductive mat (J5033) and wrist strap (J5033-5)
for static protection of electrical parts.
②
Before disassembling, be sure to remove batteries or AC power wires.
③
When disassembling, make sure to memorize the processing state of wires and FPC, screws to be xed
and their types, etc.
④ Because the low pass lter of the imaging CCD PCB is easily damaged, handle it with enough care.
Points to notice for Lead-free solder products
・ Lead-free solder is used for this product.
・ For soldering work, the special solder and soldering iron are required.
・ Do NOT mix up lead-free solder with traditional solder.
・ Use the special soldering iron respectively for lead-free solder and lead solder.
They cannot be used in common.
INC

Nikon D60 Specifications

General

Megapixel	10.2 MP
Sensor type	CCD
Maximum image resolution	3872 x 2592 pixels
Interface	USB
Digital SLR	Yes
Video capability	No
Compatible memory cards	sd
Display diagonal	2.5 \
Display resolution (numeric)	230000 pixels
Product color	Black
Battery type	EN-EL9
Battery capacity	1000 mAh
Flash modes	auto, Flash off
Scene modes	Children, Close-up (macro), Night portrait, Portrait, Sports, Landscape (scenery)

Weight and Dimensions

Depth	64 mm
Width	126 mm
Height	94 mm
Weight	495 g
