Nikon D60 Repair Manual

- Ａ  ･ -
logo_Q0650_forGraphic
071004_Gdesign_ito
VBA21001-R.3753.A
(1) AE CCD alignment inspection and adjustment (ref. Page A28, A29 for details
）
(2) AE accuracy inspection and adjustment
(3) Aperture accuracy inspection
(4) Adjustment for battery check level [Use the
Power connector
EP-5 and stabilized power supply.]
(5) Built-in SB ash inspection and adjustment
〔Tools required〕ref. Page A33.
AE inspection and adjustment
・
Battery check voltage level adjustment
Connect the Power connector (EP-5) of which the wire is processed to the camera. Then make adjustment.
・
Built-in SB ash inspection and adjustment
Set the distance between camera and ash meter to 1 m, and inspect and adjust the light volume of the built-in
SB. (ref. adjustment software for details)
・
AE accuracy inspection and adjustment
When AE accuracy inspection and adjustment is made, two types of lenses (AF50/1.4D, AF28/2.8D and
AF70-300/4-5.6D or AF-SVR70-300/4.5-5.6G) are used.
Caution:
AE accuracy is not inspected in the traditional manner that uses the exposure value of the shutter tester. The
metering value is displayed on PC screen.
AF inspection and adjustment
Note: When the adjustment software is used for the rst time, prepare three D60 cameras and measure by
"WRITING of AF ADJ. LENS OFFSET VALUE" on the main menu. If "LDATA.DAT"of D40(D40X)
is obtained under the same environment, copy it into a folder of D60 adjustment software, and change
"D40(D40X)" to "D60" of the le name "D40LDATA" to become usable.
(1) AF accuracy adjustment (Make the overall following adjustment.)
(2) YAW, PITCH inspection and adjustment
(3) LARK adjustment (inc. CCD output adjustment)
(4) AF shift adjustment
〔Tools required〕
1. In common with all adjustment/inspection items
ref. Page A33.
2. When inspecting AF accuracy
(1) AF
adjustment Z lens (J18266)
(2)
AF adjusting tool (J15259
）
(3)
Lens holder (J15280)
(4)
AF accuracy measuring chart D40 (
J18415), Chart board (J15409)
(5)
Chart illuminator for AF
（J15264）
3. When adjusting YAW, PITCH
YAW, PITCH tool
（
J18230
）
4. When adjusting LARK
The above tool when inspecting AF accuracy
In "AF shift adjustment", the distance from the bayonet reference plane to the imaging area (CCD) is calculated
by the actual shot photo, and its error is recorded in EEPROM as compensation amount, and adjusted.
INC

Nikon D60 Specifications

General

Megapixel	10.2 MP
Sensor type	CCD
Maximum image resolution	3872 x 2592 pixels
Interface	USB
Digital SLR	Yes
Video capability	No
Compatible memory cards	sd
Display diagonal	2.5 \
Display resolution (numeric)	230000 pixels
Product color	Black
Battery type	EN-EL9
Battery capacity	1000 mAh
Flash modes	auto, Flash off
Scene modes	Children, Close-up (macro), Night portrait, Portrait, Sports, Landscape (scenery)

Weight and Dimensions

Depth	64 mm
Width	126 mm
Height	94 mm
Weight	495 g
