Nikon D60 Repair Manual

- Ｄ  ･ -
logo_Q0650_forGraphic
071004_Gdesign_ito
VBA21001-R.3753.A
Approx. 2cm
Approx. 4cm
SB pop-up
・
Cut the tracing lm sheet, etc into the below size of piece.
Then insert it into the clearance of the top cover pop-up
part as shown right, and raise the SB by sliding the sheet in
the direction of the arrow.
㧍
内部に高電圧部あり。カバーを外す時は感電に注意すること。
カバーを外した後は、修理指針の指示に従ってメインコンデン
サーの放電を必ず行うこと。
警告
WARNING
Due to an internal high voltage area, take extra care not to get an
electric shock when detaching covers.
After removing the covers, be sure to discharge the main
condenser according to the instructions of repar manuals.
Covers
#5610×2
#5610×2
#29
#26
#131
#5120
#670
#792C
#626
#750×2
#B24
#6074
Adhesive: Super X
Adhesive: AlonAlfa
(Quick drying glue)
Adhesive: Super X
・
Take out the four screws (#5610) and
the screw (#626).
・
Remove the front cover unit (#B24) and
[#131].
(Be careful not to drop [#131].)
INC

Nikon D60 Specifications

General

Megapixel	10.2 MP
Sensor type	CCD
Maximum image resolution	3872 x 2592 pixels
Interface	USB
Digital SLR	Yes
Video capability	No
Compatible memory cards	sd
Display diagonal	2.5 \
Display resolution (numeric)	230000 pixels
Product color	Black
Battery type	EN-EL9
Battery capacity	1000 mAh
Flash modes	auto, Flash off
Scene modes	Children, Close-up (macro), Night portrait, Portrait, Sports, Landscape (scenery)

Weight and Dimensions

Depth	64 mm
Width	126 mm
Height	94 mm
Weight	495 g
