111Service Manual – SC401, SCRUBTEC 344 24 - Electrical System (Battery)
Battery Charger Setting and Dipswitches Conguration
1. If equipped remove the ignition key, then disconnect the red battery connector.
2. Unscrew the 4 screws (A) and remove the electronic component compartment cover (B).
3. Unplug the connection of the on-board battery charger.
4. Unscrew the 4 screws (C) and remove the on-board battery charger (D).
Figure 5:
A
C
D
A
C
A
CC
BA
