164Service Manual – SC401, SCRUBTEC 344 40 - Recovery System
Removal and Installation
Vacuum Motor Unit
Removal
1. Switch off the machine and disconnect the battery connector.
2. If present, drain the recovery tank, then lift it.
3. Disconnect the connector (A).
4. Unscrew the 5 screws (B) and the tie cable (C), then remove the Vacuum motor unit (D) from the
machine.
Figure 6:
A
D
C
B
