153Service Manual – SC401, SCRUBTEC 344 38 - Squeegee System
Maintenance and Adjustments
Squeegee Cleaning
Note: The squeegee must be clean and its blades must be in good conditions in order to get a good
drying.
WARNING: It is advisable to wear protective gloves when cleaning the squeegee because there
may be sharp debris.
1. Drive the machine on a level oor.
2. Ensure that the machine is off and the ignition key has been removed.
3. Loosen the handwheels and remove the squeegee.
4. Wash and clean the squeegee. In particular, clean the compartments (A) (Figure 2) and the vacuum hole
(B). Check that the front blade (C) and the rear blade (D) are integral and free from cuts and lacerations;
if necessary replace them.
5. Assemble in the reverse order of disassembly.
Figure 2:
C
D
C
A
B
A
D
