84Service Manual – SC401, SCRUBTEC 344
10 - Chassis System
Chassis (Main Parts)
The chassis function is primarily performed by the solution tank, the support housings for the wheels and
working mechanisms are integrated in the gear motor unit (Drive model) and the rear frame.
Reference to the Figure:
• Deck raising levers
• Frame integrated in the drive motor
• Front wheels
• Rear pivoting wheels support frame with squeegee raising/lowering system
Figure 1:
Drive gear motor with
integrated frame
Rear pivoting wheels support frame with
squeegee raising/lowering system
Brush deck raising levers
