Notifier AFP-2800 Operator's Manual

AFP-2800 - Fire Indicator Panel – Panel Operation Page 27
© N
OTIFIER
I
NERTIA
P
TY
L
TD
, 2001
WWW
.
INERTIA
.
COM
.
AU
S
ERVICE
M
ENU
- L
IST
– F
LASH
S
CAN



– D
ETECTORS
- S
TATUS
This screen will show a reading of the selected FlashScan detector updated every 3 seconds, 255 times.
The detector’s current configuration is displayed together with “live readings” as shown below.
Heat Detector Smoke Detector
L1D2 > APARTMENT 1 BATHROOM
Poll Mode > Flashscan Mode
Programmed As > FST-751/FDX-551 HEAT
Actual Device > FST-751 HEAT
Device State > NORMAL
Device Status > NORMAL
LED Status > Polling
Detector Values:
Alarm = 0% Peak Temperature = 30 C
Temperature = 24 C Day Alm Sensitivity = 5
Night Alarm Sens = 1
Device Scanned 255 Times .
FLASHSCAN MENU – STATUS
A = 0
F = 0
I = 0
N = 0
01 OCT 1999 14:44:37
F-NEXT
FS-TEST BACK
L1D3 > APARTMENT 1 BEDROOM
Poll Mode > Flashscan Mode
Programmed As > FSP-751/SDX-551 PHOTO
Actual Device > FSP-751 PHOTO
Device State > NORMAL
Device Status > NORMAL
LED Status > Polling
Detector Values:
Alarm = 0% Peak Alarm Value = 10%
Prealarm = 0% Day Alm Sensitivity = 5
Day PreAlarm Sens = 5
Night Alarm Sens = 1
Night PreAlarm Sens = 1
Device Scanned 255 Times .
FLASHSCAN MENU – STATUS
A = 0
F = 0
I = 0
N = 0
01 OCT 1999 14:44:37
F-NEXT
FS-TEST BACK
Actions:
• Press the F-NEXT
buttons to move to the next installed point.
• Press the FS-TEST
button to enter test menu for FlashScan detectors.
• Press BACK
to return to the previous screen.
Explanations of terms:
Variable Range Description
Poll Mode
FlashScan or CLIP Shows the current polling protocol being used. FlashScan =
10 detectors at a time, CLIP = 1 detector at a time. Polling
mode is auto sensed at start-up
Programmed As 6 Types Detector type programmed into panel
Actual Device 6 Types Detector type physically seen on loop.
Device State Normal/Active/Alarm Shows alarm or activated condition of point.
Device Status 20 fault types Detailed description of fault condition. Ie: “No Response”
LED Status 4 Types Polling, On, Off, Polling ID
Alarm % Current Percentage of alarm or Degree Celsius
Prealarm % Current Percentage of Pre-alarm
Peak Alarm
Value
% or
O
C Highest reading since last reset.
Sensitivities 1-9 Detector sensitivity for day/night, alarm/pre-alarm. Please
refer to page 71 for explanation information on sensitivity
settings.
