Page 28 AFP-2800 - Fire Indicator Panel – Panel Operation
© N
OTIFIER
I
NERTIA
P
TY
L
TD
, 2001
WWW
.
INERTIA
.
COM
.
AU
Service Menu - List – FlashScan – Detectors – Status - Test
This screen performs operation tests on the selected detector.
L1D2 > APPARTMENT 1 BATHROOM
Poll Mode > Flashscan Mode
Programmed As > FST-751/FDX-551 HEAT
Actual Device > FST-751 HEAT
Device State > NORMAL
Device Status > NORMAL
LED Status > Polling
Detector Values:
Alarm = 0% Peak Temperature = 30 C
Temperature = 24 C Day Alm Sensitivity = 5
Night Alarm Sens = 1
USE BUTTONS TO SELECT TEST .
FLASHSCAN MENU – TESTING
A = 0
F = 0
I = 0
N = 0
01 OCT 1999 14:44:37
FS-OFFFS-ON
FS-ALM STATUSFS-FLT
Actions:
Press the FS-ON
button to turn detector LED’s ON
Green (Red if CLIP). (This test is useful for locating
detectors at same address)
Press the FS-OFF
button to return the detector LED’s
to the Automatic Polling Mode
Press the FS-ALM
button to perform an ALARM
TEST on the detector.
Press the FS-FLT
button to perform an FAULT TEST
on the detector.
Press the STATUS
button to return to the read status
screen.
Note: Each time a test is performed, the screen will automatically return to the STATUS screen so the data becomes live once
again. To perform another test, simply press
FS-TEST
again.
S
ERVICE
M
ENU
- L
IST
– F
LASH
S
CAN
– D
ETECTORS
- C
HANGE
This screen will allow you to change FlashScan detector information and options on a point by point basis.
SELECTED POINT : L1D1
NAME > APPARTMENT 1 BATHROOM
DEVICE TYPE > FSP-751/SDX-751 PHOTO
ZONE NO. > 2
ZONE TYPE > SMOKE
ALARMED? (Y/N) > Y
LATCHED? (Y/N) > Y
TIMED? (Y/N) > N
AVF? (Y/N) > N
SENSITIVITY 1-9: (1 is most sensitive)
Day Alarm 5 Day Pre-Alarm 4
Night Alarm 1 Night Pre-Alarm 1
FLASHSCAN MENU – PROG
A = 0
F = 0
I = 0
N = 0
01 OCT 1999 14:44:37
BACKSP
ENTER
PLEASE ENTER THE INFORMATION BELOW
Actions:
Press BACKSP
to backspace an incorrect character.
Press ENTER
to step through options.
Press YES
or NO buttons when highlighted to
answer Y/N options.
Use external QWERTY keyboard to edit descriptors
and zone type.
The numeric keypad can be used for number entries
only.
When entering device type, an option list will appear at
the bottom of the screen.
Refer to appendix for more information on options and
sensitivity settings.
You will be prompted Yes/No to save changes when
finished.
