AFP-2800 - Fire Indicator Panel – Panel Operation Page 29
©
N
OTIFIER
I
NERTIA
P
TY
L
TD
,
2001
WWW
.
INERTIA
.
COM
.
AU
S
SS
S
ERVICE
ERVICE ERVICE
ERVICE
M
MM
M
ENU
ENU ENU
ENU
- L
- L- L
- L
IST
IST IST
IST
–
– –
– F
FF
F
LASH
LASHLASH
LASH
S
SS
S
CAN
CANCAN
CAN
- M
- M- M
- M
ODULES
ODULESODULES
ODULES
This screen will provide a list of modules (1-159) on the loop selected showing the name of each module alongside
its address. From this screen you can do a live read status of the point or change the configuration of the point.
Modules that are not installed are listed as “NOT INSTALLED”, performing a change automatically installs the
point.
USE BUTTONS TO SELECT DEVICE:
L1M1 BREAK GLASS PANEL
L1M2 BREAK GLASS ENTRY FOYER
L1M3 NOT INSTALLED
L1M4 NOT INSTALLED
L1M5 NOT INSTALLED
L1M6 NOT INSTALLED
L1M7 NOT INSTALLED
L1M8 NOT INSTALLED
L1M9 NOT INSTALLED
L1M10 EWIS OUTPUT #1
L1M11 EWIS OUTPUT #2
L1M12 NOT INSTALLED
L1M13 NOT INSTALLED
L1M14 NOT INSTALLED
L1M15 NOT INSTALLED
L1M16 NOT INSTALLED
L1M17 NOT INSTALLED
FLASHSCAN LIST – MODULES
A = 0
F = 0
I = 0
N = 0
01 OCT 1999 14:44:37
DOWNUP
01 OCT 1999 14:44:37
UP
01 OCT 1999 14:44:37
DOWNUP
STATUS CHANGE BACK
Actions:
Use the UP
and DOWN buttons to select detector.
Use the STATUS
button to perform a live point read on
the module.
Use the CHANGE
button to edit the modules setting
and/or change its name.
Press the BACK
button to return to the previous
screen.
Note: You can also use the arrow keys, the Page Up and Page Dn keys on an external keyboard for scrolling functions.
