To remove a FlashScan
detector or module from the panel’s memory, it must be removed from the CPU memory
and the LCM memory consecutively.
This service menu allows for the permanent removal of a point.
• You will be prompted for a loop number and a detector or module number.
• You will then be prompted to confirm removal by a Yes or No action.
If you select YES the detector / module will be permanently removed from the system.
4.3.6.5
4.3.6.54.3.6.5
4.3.6.5 S
SS
S
ERVICE
ERVICE ERVICE
ERVICE
M
MM
M
ENU
ENU ENU
ENU
–
– –
– F
FF
F
LASH
LASHLASH
LASH
S
SS
S
CAN
CANCAN
CAN
- L
- L- L
- L
OOP
OOP OOP
OOP
U
UU
U
TILITIES
TILITIESTILITIES
TILITIES
This menu item allows several diagnostic functions to be performed on the loops themselves.
Firstly you will prompted to enter a loop number.
Then the screen will appear as follows:
Loop wiring style -> Open
Detector Poll Style -> FLASHSCAN
Module Poll Style -> FLASHSCAN
FLASHSCAN MENU - LOOP
01 OCT 1999 14:44:37
F-NEXTF-PREV BACK
LOOP 1 SELECTED:
USE BUTTONS TO SELECT FUNCTION:
A = 0
F = 0
I = 0
N = 0
AUTOPRG CLIP
Action:
• Use the F-PREV
and F-NEXT buttons to move to
the next / previous loop.
• Press the AUTOPRG
button to Auto Program the
selected loop. This will add any new detectors and
modules placed on the loop.
• Pressing the CLIP
button will change the loops
polling mode to clip mode. If the loop is already in
clip mode, the button will toggle to FLASHSCAN
.
• Pressing the BACK
button will return you to the
service menu.
