214
Troubleshooting
Clearing a Media Missfeed From Tra
y 1
1
Remove th
e dust cover from T
ray 1.
2
Carefully pull out the mi
ssed media.
"
If the media cannot be
removed, inst
ead of pulli
ng it
with extreme force, cl
ear the
media missfeed according to
the procedure described in
“Clearing a Media Missfee
d
in the Machine” on
page
206.
3
Reattach the dust cover
.
4
Press the
Start
key
.
M
213
215
