99
Media Handling
3
Gently close th
e ADF cover
.
"
T
ake care not to trap your fin-
gers when closing the
ADF
cover
.
Loading a document into the ADF
1
Put the document into the ADF do
c-
ument feed tray face up.
"
Before loadi
ng a document
into the ADF
, check that no
document pages remain on
the original glass.
"
Load the document pages so
that the top of the
document
is toward the back or the
right side of the machine.
2
Adjust the document guides
to the
document size.
Document
98
100
