7. TROUBLESHOOTING PROCEDURES
7.1 Precautions prior to repair
(1) Confirm the basic check items indicated in the User's Manual.
(2) Through hearing from the user, obtain information, as far in detail as possible, on the situation concerning the fault.
(3) Inspect the printer in a condition close to the actual situation in which the fault occurred.
7.2 Items to be checked prior to taking action on abnormal images
(1) Check to see if the printer is operated in an adequate environment.
(2) Check to see if the consumables (toner, drum cartridges) are replaced properly.
(3) Check to see if the right paper is used. See the paper specifications.
(4) Check to see if the drum cartridges are installed properly.
7.3 Precautions when taking action on abnormal images
(1) Do not bring your hand or any object in contact with the surface of the OPC drum.
(2) Do not expose the OPC drum to direct sun.
(3) Do not touch the fuser unit, which can be very hot.
(4) Do not expose the image drums to light for over five minutes at the room temperature.
7.4 Preparations for troubleshooting
(1) Display of LCD
The breakdown situation of this machine is display in LCD.
Do an appropriate trouble repair based on information displayed in LCD.

Oki MC561 Specifications

Printing Specifications

Print Speed	Up to 27 ppm color, 31 ppm black & white
Time to First Page	As fast as 8 seconds in color, 7.5 seconds in black & white
Print Resolution	Up to 1200 x 600 dpi

Copying Specifications

Copy Speed	Up to 27 cpm color, 31 cpm black & white
First Copy Out	As fast as 14 seconds in color, 12 seconds in black & white
Copy Resolution	Up to 600 x 600 dpi

Scanning Specifications

Scan Type	Color and black & white flatbed
Scan Resolution	Up to 1200 x 1200 dpi
Scan Speed	Approx. 3 sec./page color, approx 2 sec./page black & white at 300 dpi

Fax Specifications

Fax Modem	33.6 Kbps Super G3
Transmission Speed	3 seconds/page
Fax Resolution	Up to 200 x 400 dpi

System Memory

Standard Imaging RAM	256 MB
Max Imaging RAM	768 MB
SD Card Storage	4 GB standard; 16 GB optional

Paper Handling

Scanner RADF Capacity	Up to 50 letter/legal sheets
Standard Input	350 sheets (250 sheets via Main Tray + 100 sheets via MPT)
Maximum Input	880 sheets (with optional 530-sheet 2nd Paper Tray)

Environmental Specifications

Size	16.8" x 20" x 17.5" (42.7 cm x 50.9 cm x 44.4 cm)
Weight	63 lb. (29 kg)
Power Consumption	Operating Normal 570W; Max 1170W; Idle 100W; Power Save 20W; Deep Sleep <1.5W
