10-3
Mounted Objects Section 8-2
Additional Informa-
tion for DeviceNet
Device Profiles
The following device profiles contain more detailed DeviceNet specifications for DeviceNet communications if
more information needs to be registered in the scan list.
8-2 Mounted Objects
Identity Object (0x01)
Message Router Object (0x02)
General data Compatible DeviceNet Specifications Volume I - Release 2.0
Volume II - Release 2.0
Vendor name OMRON Corporation Vendor ID = 47
Device profile name Slaves: Generic Device Profile number = 0
Manufacturer catalog number N129
Manufacturer revision 1.01
Physical conformance
data
Network current consumption 50 mA max.
Connector type Open plug
Physical layer insulation No
Supported indicators Module, Network
MAC ID setting Software switch
Default MAC ID 1
Baud rate setting Automatic recognition
Supported baud rates 125 kbps, 250 kbps, and 500 kbps
Communications data Predefined Master/Slave connection set Group 2 only server
Dynamic connection support (UCMM) No
Explicit message fragmentation support Yes
Object class Attribute Not supported
Service Not supported
Object
instance
Attribute ID Contents Get (read) Set (write) Value
1 Vendor No No 47
2Device type Yes No 0
3 Product code Yes No 505
4 Revision Yes No 1.1
5 Status (bits supported) Yes No Bit 00 only
6 Serial number Yes No Unique for each Unit
7 Product name Yes No K3HB-DRT
8 State No No
Service DeviceNet service Parameter option
05 Reset No
0E Get_Attribute_Single No
Object class Attribute Not supported
Service Not supported
Object instance Attribute Not supported
Service Not supported
Vendor specifica-
tion addition
None
