Omron K3HB-R User Manual

1-22
Commands and Responses (CompoWay/F Communications) Section 1-9
CompoWay/F
Communications
Response codes: The above indicates a normal end. For the response codes,
see 1-7 Operation Commands (CompoWay/F Communications) (page 1-11).
Operation State
Note Measurements outside the display range and no-measurement status do not
generate errors and thus may be possible even for an operation state of 00.
Related Information
Note (1) The bit will be ON (1) or when an error occurs and otherwise will be OFF
(0).
(2) Information is in the same order as status information.
1-9-20 Echo Back Test
Command
This command is used to perform an echo back test.
The command can be used in any state of the K3HB.
Keep the test data within the following ranges depending on the communica-
tions data length.
Response
Response codes: The above indicates a normal end. For the response codes,
see 1-7 Operation Commands (CompoWay/F Communications) (page 1-11).
Operation state Description
00 Operating (no errors in setting area 0, see note)
01 Stopped (all other situations)
Bit position Status
7 Not used
6 Not used
5 Not used
4 Not used
3 Input error B Present value
2 Input error A
1 Measurement outside the dis-
play range
0 No-measurement status
Communications data
length
Description
7 bits ASCII code H'20 to H'7E
8 bits ASCII code H'20 to H'7E or H'A1 to H'FE
"08" "01" 0 to 200 bytes
SRC
Test data
MRC
"08" "01" "0000" 0 to 200 bytes
SRC
Test dataResponse code
MRC
