Commands and Responses (CompoWay/F Communications) Section 1-9
CompoWay/F
Communications
Response
Response codes: The above indicates a normal end. For the response codes,
see 1-7 Operation Commands (CompoWay/F Communications) (page 1-11).
1-9-18 Read Machine Attributes
Command
This command reads the K3HB model and communications buffer size.
The command can be used in any state of the K3HB.
Response
Response codes: The above indicates a normal end. For the response codes,
see 1-7 Operation Commands (CompoWay/F Communications) (page 1-11).
Model
1-9-19 Controller Status Read (CompoWay/F Communications)
Command
This command reads the operation state of the K3HB.
The command can be used in any state of the K3HB.
Response
"30" "05" "0000"
Response code
SRCMRC
"05" "03"
SRCMRC
AB
Symbol Series Symbol Input
X Analog input VD DC voltage
AD AC voltage
VA DC current
AA AC current
V mV input LC mV
S Linear Sensor input SD Linear Sensor
H Temperature input TA Temperature
R Rotary pulse input NB NPN/voltage pulse input
PB PNP input
P Time interval input NB NPN/voltage pulse input
PB PNP input
C Up/Down counting pulse
input
NB NPN/voltage pulse input
PB PNP input
"05" "03" "0000" "00D9"
Buffer sizeFormatResponse codeSRCMRC
B-K
∗Bytes 8 and 9 are blank
3
H
"06" "01"
SRCMRC
"06" "01" "0000"
Related information
Operation
state
MRC SRC Response code
