Omron K3HB-R User Manual

1-16
Commands and Responses (CompoWay/F Communications) Section 1-9
CompoWay/F
Communications
Response
Response codes: The above indicates a normal end. For the response codes,
see 1-6 Writing to the Variable Area (page 1-10).
1-9-6 Setting Data Compound Write (CompoWay/F Communications)
Command
Multiple setting data items can be written by sending a single command. Up to
12 items can be written even if the addresses are not contiguous.
To specify the variable type or address, see SECTION 2 List of Settings
(page 2-1).
Setting data of setting area 1 is written in setting area 1. An error will result if
written in setting area 0.
To use this command, “Write via communications” must be enabled using the
“Write via communications” operation command.
Response
Response codes: The above indicates a normal end. For the response codes,
see 1-6 Writing to the Variable Area (page 1-10).
1-9-7 Monitor Value/Setting Data Compound Read Store (Write)
Command
This command is used to store the addresses of multiple monitor values or
setting data that you wish to read.
The stored monitor values or setting data can be read by sending a single
“Monitor value/setting data compound store read” command. Up to 20 items
can be stored, even if the addresses are not continuous.
"01" "02" "0000"
Response code
SRCMRC
Variable type Address Setting data (explanation)
“C1” to “C2” “0000” to “0004” Setting data of setting area 0
“C4” to “CB” “0000” to “0027” Setting data of setting area 1
"01" "13" "00"
Bit position
AddressMRC SRC
Setting data
Data
"00"
Bit position
AddressVariable type
Setting data
Data
Variable
type
"01" "13" "0000"
Response code
SRCMRC
Variable type Address Setting data (explanation)
“C0” “0000” to “0004” Monitor values
“C1” to “C2” “0000” to “0004” Setting data of setting area 0
“C4” to “CB” “0000” to “0027” Setting data of setting area 1
"01" "11" "00"
Bit position
"00"
Bit position
Read address
Read address
Read addressMRC SRC
Variable
type
"00"
Bit position
Variable
type
Variable
type
