1-11
Operation Commands (CompoWay/F Communications) Section 1-7
CompoWay/F
Communications
1-7 Operation Commands (CompoWay/F Communications)
Operation commands are sent using the following FINS-mini command text
format.
Command FINS-mini Command Text
Operation commands for the K3HB are shown in the following table.
Note A software reset will not respond (no service PDU response).
Response FINS-mini Response Text
Response Codes
Data name Explanation
MRC/SRC Specify the FINS-mini operation command.
Operation code Specify an operation code.
Related information Specify information related to the command.
Operation code Description Related information
00 Write via communications 00: OFF (Disabled)
01: ON (Enabled)
01 Reset 00
02 Bank selection 00 to 07: Bank 0 to 7
03 Zero execute/cancel 00: Zero cancel
01: Zero execute
06
Software reset
00
07 Move to setting area 1 00
08 Move to protect level 00
0B Initialize settings 00
"30" "05"
Instruction
code
Related
information
SRCMRC
2222
Data name Explanation
MRC/SRC FINS-mini command text appears here.
Response code Result of execution of the command.
Response
code
Error name Explanation
“1001” Command length too
long
The command is too long.
“1002” Command length too
short
The command is too short.
“1100” Parameter error Operation code or related information is not
correct.
"30" "05"
Response code
(MRES/SRES)
SRCMRC
22 4
