1-17
Commands and Responses (CompoWay/F Communications) Section 1-9
CompoWay/F
Communications
To specify the variable type or address, see SECTION 2 List of Settings
(page 2-1). The upper limit of an address will vary depending on the variable
type.
This command can be used in both setting area 0 and setting area 1.
Response
Response codes: The above indicates a normal end. For the response codes,
see 1-5 Reading the Variable Area (page 1-9).
1-9-8 Monitor Value/Setting Data Compound Read Store Check (Read)
Command
This is used to check the contents that were stored using “Monitor value/set-
ting data compound read store.”
Response
Response codes: The above indicates a normal end. For the response codes,
see 1-5 Reading the Variable Area (page 1-9).
1-9-9 Monitor Value/Setting Data Compound Store Read
Command
This is used to read by a single command the multiple monitor values or set-
ting data items that were stored using “Monitor value/setting data compound
read store (write).”
This command can be used in both setting area 0 and setting area 1.
If an area type error or a setting data error occurs in any of the data being
read, no data will be read.
Response
Response codes: The above indicates a normal end. For the response codes,
see 1-5 Reading the Variable Area (page 1-9).
"01" "11" "0000"
Response code
SRCMRC
"01" "12"
SRCMRC
"01" "12" "0000"
Type
Response code
Read address
Read addressMRC SRC
"00"
Bit position
Type
Variable
type
Variable
type
"01" "10"
SRCMRC
"01" "10" "0000"
Type
Response code
Data
Data
Monitor value / Setting data
MRC SRC
Monitor value / Setting data
Variable type
Type
Variable
type
