6-2 NX1P Programming in ST
6-2-1 Writing an ST Program for NX1P
You can create an ST program for the NX1P in two ways:
1. Using the ST language only
2. Partly using the ST language within a ladder program (inline ST)
In the second method, the ST program can be executed under a specified condition (e.g.,
when an input changes to TRUE) or can always be executed.
Additional Information
Adding a program and assigning the program to a task
(1) Right-click Programs and select Add − Ladder or Add − ST from the menu.
(2) Double-click
Task Settings under Configurations and
Setup in the Multiview Explorer and then click the Program
Assignment Settings Button. Select the program to assign
to Primary Task and set the initial status.
