Omron NX1P User Manual

32
2-2 Installing the Sysmac Studio
2-2-1 Installing the Sysmac Studio
The Sysmac Studio is the support software to configure, program, debug, and simulate
NJ/NX-series Controllers.
Use the following procedure to install the Sysmac Studio on your computer.
1. Set the Sysmac Studio installation disk into the DVD-ROM drive.
The setup program is started automatically and the Select Setup Language Dialog Box is
displayed.
2. Select the language to use, and then click the OK Button.
The Sysmac Studio Setup Wizard is started.
3. Follow the wizard to install the Sysmac Studio.
4. Restart your computer after the Sysmac Studio has been successfully installed.
2-2-2 Requirements for Installation
The system requirements for the Sysmac Studio are given in the following table.
OS
CPU
RAM
Display
Windows 7
32-bit or 64-bit edition
Windows 8
32-bit or 64-bit edition
Windows 8.1
32-bit or 64-bit edition
Windows 10
32-bit or 64-bit edition
Minimum IBM AT or compatible with
Intel
®
Celeron
®
processor 540
(1.8 GHz)
2 GB XGA
1,024 x 768
16 million
colors
Recommended IBM AT or compatible with
Intel
®
Core™ i5 M520
processor (2.4 GHz) or the
equivalent
4 GB
min.
WXGA
1,280 × 800
16 million
colors
Precautions for Correct Use
When the CX-One version 4 or lower has been installed, uninstall it before installing
the Sysmac Studio.
