76
4-2-3
Creat
ing a Projec
t
1.
Start the Sysma
c Studio.
2.
Enter the proj
ect nam
e. Select
N
X1P
2, 9
024D
T/
1140D
T
for
the
devi
ce
para
meter
and
1.13
(version in
dicated o
n the NX1P)
f
or the
vers
ion
par
ameter
, and then cli
ck the
Create
Button.
