35
3-1 Programming with the Sysmac
Studio
3-1-1 Programming Procedure
This section describes how to create a simple ladder program using pushbutton switches and
lamps.
The overall programming procedure is given below.
3-1-2 Creating a Project
1. Start the Sysmac Studio.
2. Enter the project name.
Select NX1P2, 9024DT/1140DT for the device parameter and 1.13 (version indicated on the
NX1P) for the version parameter, and then click the Create Button.
Connecting NX1P to debug program using physical devices
Assigning variables to connected I/O devices in I/O Map
To Next Page
