18
1-2-3 Easy Motion Programming
Previously
The traditional PLC (e.g., CJ2) used three different software applications for Position Control
Unit settings, ladder programming, and Servo System settings. The user had to create a
program while monitoring and tuning the settings.
Programming the NX1P
Operations such as turning ON the Servo, homing, and positioning can be described in one
program by using motion FBs.
Processes are executed from top to bottom, which makes the program easy to read.
The Sysmac Studio integrating ladder programming, motion, and Servo configuration
facilitates positioning control. Simple monitoring and modification!
To Next Page
