26
1-4 Programming Software
1-4-1 Programming Software Sysmac Studio
The Sysmac Studio
The Sysmac Studio provides an integrated development environment to configure, program,
debug, and maintain NJ/NX-series Machine Automation Controllers.
Features
1. One software integrates configuration, programming and monitoring
2. Programming with variables. Supports the ladder and ST languages and FBs
*1
based on IEC 61131-3
3. PLCopen function blocks for easy programming of complex motion profiles, and
Cam Editor for quick implementation of cam motion profiles
4. Integrated simulation and debugging
Motion trajectories in 3D can be pre-tested, and simulation of programs can be
performed. This reduces set-up and tuning time.
*1. ST language (Structured Text language), FB (Function Block)
Programming Motion control
HMI Vision sensors
Safety Simulation
