Omron Sysmac NJ-series User Manual

10-3
10 FTP Server
NJ/NX-series CPU Unit Built-in EtherNet/IP Port User’s Manual (W506)
10-2 FTP Server Function Details
10
10-2-1 Supported Files
10-2 FTP Server Function Details
The file system in the Controller that can be accessed by the built-in EtherNet/IP port includes files in
any SD Memory Card mounted in the CPU Unit. The directory tree is shown below.
A connection is initially made to the root directory.
Additional Information
• The date of the MEMCARD1 directory displayed for ls, dir, or mkdir commands in the root
directory is the date of the file system volume label.
• The login date is displayed for MEMCARD1 if a volume label has not been created.
Input the FTP login name and password to login to the built-in EtherNet/IP port from an FTP client appli-
cation. Use the Built-in EtherNet/IP Port Settings in the Sysmac Studio to set the FTP login name and
password.
Additional Information
When a general-purpose FTP application is used, you can use a graphical user interface similar
to Explorer to transfer and read files.
 Login Name and Password Setting
The FTP login name and password are not set by default. Use the Built-in EtherNet/IP Port Settings
to set any login name and password.
 Login Messages
10-2-1 Supported Files
10-2-2 Connecting to the FTP Server
Status Message
Normal connection 220 xxx.xx.xx.xx FTP server ready.
xxx.xx.xx.xx: CPU Unit model (example: NJ501-1300)
Connected to maximum num-
ber of connections (6)
530 FTP server busy, Goodbye.
/: root
MEMCARD1: SD
usr
bin
Used by system
dev
