Onkyo CR-N7 User Manual

26
Playing a CD—Continued
MP3 CDs may store a group containing groups across
some hierarchies as shown in the illustration below. In
MP3 CDs, you can use the Navigation and All Group
modes to locate track stored on the CDs. When locating
a track, the Navigation mode allows you to trace through
the hierarchies while the All Group mode to select the
group directly.
When you do not select any specific track or group to
play, the unit starts playing tracks on the MP3 CD from
Track 1 and the rest of the tracks are played in the
numerical order of track numbers shown in the illustra-
tion above.
Selecting MP3 Tracks in Navigation Mode
With Navigation mode you can select MP3 tracks by
navigating through the group hierarchy. This mode can
only be used while playback is stopped.
If in Random mode, press YES/MODE to switch to Nor-
mal mode.
Selecting MP3s
Track11
Track1
Track10
Group3
Track12
Root Group1
Group2
Track13
Group4
Track14
Track18
2-4
1
EDIT/NO/
CLEAR
1
While playback is stopped, press
GROUP for 2 seconds.
The CD receiver enters Navigation
mode.
2
Press MULTI JOG.
The name of the first group one level
down from root appears on the display.
If the disc has no groups, the name of
the first track is displayed.
3
Use MULTI JOG to select other
groups and tracks at the same
level.
Groups that do not contain MP3 tracks
or groups cannot be selected.
4
To access tracks or groups
inside another group, select the
group, and then press MULTI
JOG.
Use MULTI JOG to select the tracks
and groups in that group.
To move up a level, press EDIT/NO/
CLEAR.
NAMEGROUP
C D
MP3
NAMEGROUP
C D
MP3
NAME
C D
MP3
TRACK
1
3
2, 4
EDIT/NO/
CLEAR
Using the remote controller

Onkyo CR-N7 Specifications

Power

power supply	AC 230–240 V, 50 Hz
power consumption	68 W
stand-by power consumption	0.3 W

Audio Inputs and Outputs

analog inputs	LINE, TAPE, HDD
digital outputs	Optical: 1
analog outputs	TAPE, HDD

Amplifier Specifications

power output	14 W + 14 W (8 Ω, 40 Hz–20 kHz THD, 0.4%)
dynamic power	26 W + 26 W (4 Ω, JEITA)
damping factor	25 (8 Ω)

Tuner Specifications

fm tuning frequency range	87.5 MHz–108 MHz
am tuning frequency range	522 kHz–1611 kHz
stereo separation	40 dB (1 kHz)

CD Specifications

frequency response	10 Hz–20 kHz
audio dynamic range	92 dB
thd (total harmonic distortion)	0.009 %

Weight and Dimensions

dimensions	205 W x 147 H x 356 D mm
weight	4.3 kg
