Useful adjustment settings11
54
En
Chapter 11
Useful adjustment settings
About “Option” menus
The “Option” menu consists of two screens. To select the desired
menu, press / repeatedly to switch between Screen 1 and
Screen 2. The current screen number appears at the bottom left
corner on the screen.
Switching the vertical drive mode
(AV source only)
You can select the desired drive mode according to the programme
you watch.
1 Press HOME MENU.
2 Select “Setup” (
/ then ENTER).
3 Select “Option” (
/ then ENTER).
4 Select “Drive Mode” (
/ then ENTER).
5 Select the desired parameter (
/ then ENTER).
6 Press HOME MENU to exit the menu.
Note
• This setting can be made for each input source separately.
• This setting cannot be made when 480i, 480p, 1080i@60 Hz,
720p@60 Hz, 1080p@24 Hz or 1080p@60 Hz signals are input.
• The Drive Mode does not operate when “On” is selected in
“Game Control Pref”.
Adjusting image positions
(AV source only)
This setting adjusts the horizontal and vertical positions of images
on the flat screen TV.
1 Repeat steps 1 to 3 provided for Switching the vertical drive
mode (AV source only)
.
2 Select “Position“ (
/ then ENTER).
3 Select “H/V Position Adjust“ (
/ then ENTER).
4 Adjust the vertical position (
/ ) or the horizontal position
(
/ ).
5 Press HOME MENU to exit the menu.
Position
Auto Size : Off
Side Mask
HDMI Input
HDMI Control Setting
Blue LED Dimmer : Auto
Orbiter : Mode 1
Video Pattern
1/2
Drive Mode : 1
Colour System : Auto
Input Select
Game Control Pref : Off
Room Light Sensor : Off
Screen Protection
Label Input
2/2
(For AV source)
Auto Setup
Manual Setup
HDMI Input
HDMI Control Setting
Orbiter : Off
Label Input
(For PC source)
Drive Mode
Controls the driving frequency for output signals
Selections 1 Standard mode as well balanced
setting for general sources
2 Suitable setting for pictures with
scrolling text
3 Setting for smoother reproduction
of movies, etc.
11_Useful adjustment.fm Page 54 Thursday, August 7, 2008 12:55 PM
Downloaded From TV-Manual.com Manuals

Pioneer PDP-LX6090H Specifications

General

Depth	93 mm
Width	1465 mm
Height	876 mm
Weight	51200 g
Tuner type	Analog & digital
Pixel pitch	- mm
Aspect ratio	-
Product color	Black
Noise reduction	Yes
RMS rated power	36 W
Display diagonal	60 \
Display brightness	- cd/m²
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
HDMI ports quantity	3
Supported video modes	1080p
USB 2.0 ports quantity	1
Audio formats supported	AC3, HE-AAC
Number of OSD languages	18
S-Video inputs quantity	0
Video formats supported	MPEG2, MPEG4
Annual energy consumption	- kWh
Analog signal format system	PAL BG, PAL DK, PAL I, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.4 W
Power consumption (typical)	524 W
Digital signal format system	DVB-S, DVB-S2, DVB-T
Sound enhancement technology	SRS WOW HD, SRS, FOCUS, TruBass, SRS Definition
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, NOR, POR, RUS, SWE, TUR, UKR
Consumer Electronics Control (CEC)	Kuro Link
