9850068 R01 - 2020-2021 RZR PRO XP / XP 4 Service Manual
© Copyright Polaris Industries Inc.
RELAY / FUSE DETAILS
CIRCUIT SENDS POWER TO:
Start Relay
Start Solenoid
EPS Relay
EPS Unit
Fuel 10A Fuse
Fuel Pump
Water 10A Fuse
Water Pump
Fan 30A Fuse Radiator Fan
EPS 25A Fuse
EPS Relay
EFI 10A Fuse
EFI Relay
Lights 10A Fuse Lights B+ Splice
Taillight Harness
Headlight Switch
EFI Relay
EFI B+ Splice
Fuel Injectors
ECU
Seatbelt Switch
O2 Sensor
Brake Pressure Switch
Ignition Coil
EFI B+ Splice 2
Chassis Relay coil high
Pump Relay coil high
Pump Relay
Pump Splice
Fuel 10A Fuse
Water 10A Fuse
Unsw 10A Fuse
B+ Unswitched Fused
Splice #1
EFI Relay coil high
B+ Unswitched
Fused Splice #2
Speedometer
Diagnostic Plug
Drive 10A Fuse AWD Coil
Chassis Relay Chassis Splice
Lights 10A Fuse
Drive 10A Fuse
Accy Relay
Term Splice
Term 10A Fuse
Insr 10A Fuse
Term 10A Fuse Terminal Block ACC
Accy 10A Fuse 12V Receptacle(s)
Key 10A Fuse Key Switch
Insr 10A Fuse
Instr Fuse Out Splice
LED Light(s)
Diagnostic Plug
Speedometer
ELECTRICAL
