ENFORCER V11 PROGRAMMING GUIDE
CHOOSE MODE
CHOOSE MODE?
If an I/O board or any Zone Expander Module (Input Expander or ZEM) are used, the resistance, EOL mode and
response time of the zones can be programmed.
Please note: Alarm 4K7, Tamper 2K2 must be selected if wiring double pole to an expander.
End of Line (EOL) Range
Programs the panel to operate with dierent resistor values
[0] Alarm: 1K, Tamper: 1K. [1] Alarm: 4K7, Tamper: 2K2.
[2] Alarm: 4K7, Tamper: 4K7. [2] Wide range.
EOL Mode
EOL Mode programs all zone expanders to operate as:
[0] SR (Single End of Line - SEOL) [1] DR (Double End of Line - DEOL)
Input Response Time
Input Response time programs the time that a zone trigger must be present before the system generates an
alarm.
[01] - [30] = 100ms to 3000ms
Please note: Settings above (>) 400ms do not comply with PD 6662 / EN 50131.
INSTALL ZEMS
INSTALL ZEMS?
ZEM Address [--]
The control panel supports up to a maximum 66 zones. Zone Expansion Modules (ZEMS) are used to expand the
system to have a further 32 wireless zones, 32 wired zones or a combination of both. There are also 2 zones that
can be used on an I/O Board if connected.
ZEM address
[0] ZEM Address 0 (Zones 35-42)
[2] ZEM Address 2 (Zones 51-58)
[1] ZEM Address 1 (Zones 43-50)
[3] ZEM Address 3 (Zones 59-66)
Please note: Zones 33 and 34 are taken from the I/O board, these do not need to be addressed.
ZEM installed
[0] No
[2] EURO-ZEM32-WE
[1] ZEM8/EURO37R
Enter location
The text entered here will be displayed on the LCD display if a fault occurs on the ZEM, so the ZEM can be easily
located or referenced. For example, the location text maybe “ZEM Kitchen”, “ZEM Loft” etc.
