114Appendix A Technical specifications
Type Operation Storage, Non-operating
2U12, 2U24 5U84
Shock 5.0 Gs, 10ms (per axis) 15.0 Gs, 10ms, 10
shock pulses (X, Y, and
Z axes)
20.0 Gs, 10ms (X and Y
axes)
Vibration 0.21Grms 5Hz to 500Hz random, 30 min per axis 1.04Grms 2Hz to 200Hz random (ISTA 3E)
Relocation: ISTA3H air ride for 60 min
Acoustics N/A
Table 21 Environmental specifications (continued)
Type Description
2U 5U
Input power
requirements
100VAC to 240VAC, 50Hz to 60Hz 200VAC to 240VAC, 50Hz to 60Hz
Voltage Max output: 764W or 580W Max output: 2200W
Range: 100-240VAC, rated Range: 200-240VAC, rated
Frequency: 50-60Hz Frequency: 50-60Hz
Hot-
swappable?
HDDs and SSDs (in chassis data slots),
controller modules (CMs), and power cooling
modules (PCMs)
HDDs and SSDs (in chassis data slots), controller
modules (CMs), fan cooling modules (FCMs), and power
supply units (PSUs)
Table 22 Power specifications
