Radwin RW 2000 Series User Manual

Page 101
June 2023
Corporate Headquarters | T. +972.3.766.2900 | E. sales@radwin.com | www.radwin.com
Term
Description
BUI
Browser User Interface. Browser‐based applications that provide simple
configuration capabilities for the ODUs.
WISPA
Wireless Internet Service Provider Association. An organization that manages
registration of wireless devices that operate close to TDWR facilities run by the
FAA.
VRRP
Virtual Router Redundancy Protocol: A networking protocol that provides for
automatic assignment of available IP routers to participating hosts.
8.2 Wiring Specifications
8.2.1 ODU‐PoE Cable
The ODU‐PoE cable is a shielded/outdoor class CAT‐5e, 4 twisted‐pair 24 AWG terminated
with
RJ‐45 connectors on both ends. A cable gland on the ODU side provides hermetic sealing.
The following table shows the connector pinout:
ODU ‐ PoE RJ ‐ 45 Connector Pinout
Function
Color
PoE
ODU
Rx N
White/Green
1
1
Rx T
Green
2
2
Tx T
White/Orange
3
3
Tx N
Orange
6
6
Power
Blue
4
4
Power
White/Blue
5
5
Power
White/Brown
7
7
Power
Brown
8
8
LAN ‐ GbE PoE RJ ‐ 45 Connector Pinout
