3.7.5 Mounting the Dish Antenna and Bracket on a Standard
Mounting Kit
Figure 32 Dish antenna and bracket mounted on standard mounting kit
3.8 Installing the RADWIN 2000 Alpha EMB
Mounting Kit and Mounting the ODUs
The RADWIN 2000 Alpha EMB Mounting Kit installation and ODU mounting procedures are
described in the following sections:
• Installing the RADWIN 2000 Alpha EMB Mounting Kit
• Mounting the RADWIN 2000 Alpha EMB ODU
3.8.1 Installing the RADWIN 2000 Alpha EMB Mounting Kit
The RADWIN 2000 Alpha EMB ODU has its own mounting kit. Mount this ODU as follows:
1. Place the mount on a pole or wall:
2. Secure the mount using the worm drive “quick‐release clamps” as follows:
a. Open the clamp.
To Next Page
