Radwin RW 2000 Series User Manual

Page 102
June 2023
Corporate Headquarters | T. +972.3.766.2900 | E. sales@radwin.com | www.radwin.com
Function
Color
PoE
LAN
TxRx A
White/Green
1
1
TxRx A
Green
2
2
TxRx B
White/Orange
3
3
TxRx B
Orange
6
6
LAN ‐ GbE PoE RJ ‐ 45 Connector Pinout (Continued)
Function
Color
PoE
LAN
TxRx C & Power
Blue
4
4
TxRx C & Power
White/Blue
5
5
TxRx D & Power
White/Brown
7
7
TxRx D & Power
Brown
8
8
8.2.2 RT‐A(HBS)_HSS_Hub Unit Connection Pinout
The pinout is for the HSS Unit, used in serial HSS.
HBS/HSS Unit Connection Pinout
Color
ODU RJ‐45
HSS UNIT RJ‐45
White/Green
1
1
Green
Not connected
White/Orange
Orange
6
6
Blue
4
4
White/Blue
5
5
