Mount the ODU using a standard mounting kit (see Various ODUs Mounting Options on a
Standard Mounting Kit ), as well as the external antenna (needs its own mounting kit).
3.11.2 Connecting RADWIN 2000 Alpha EMB ODUs to an External
Antenna
Turbo Gain Antenna
Fasten the Turbo Gain antenna on the RADWIN 2000 Alpha EMB ODU using these steps:
1. Connect the cables to the ODU.
2. Seal the cables (see Waterproofing ).
3. Connect the Turbo Gain antenna.
4. Close the screws of the Turbo Gain antenna.
5. Seal the connectors on the Turbo Gain antenna using the sealing tape.
