Rain Bird ESP-SMT User Manual

ESP-SMT Smart Modular Control System
37
d. The Temp. Below: value will begin
to blink. Press the - or + button(s) to
set the desired temperature value;
then press the NEXT button.
!
NOTE: The Suspend Watering
When Temp. Below XX feature
allows you to set a temperature
threshold when irrigation will be
suspended to prevent potential
freeze damage to the system
components.
Advanced Zone Setup
Allows you to assign each zone to:
• Use/Not Use a Master Valve / Pump
Start Relay.
• Use/Not Use the ESP-SMT Rain Gauge
information.
H
If you would like to set a specic zone
to use or not use a Master Valve or
Pump Start Relay and/or the rainfall
measurement information gathered
from the ESP-SMT Rain Gauge:
Press the UP and Down arrow
button(s) until Advanced Zone
Setup is blinking on the display;
then press the SELECT button.
I
The ADVANCED SETUP screen
will appear and the Zone Number
begins to blink;
a. Press the - or + button(s) until the
desired Zone number is displayed;
then press the NEXT button.
b. Use Master Valve: YES will begin to
blink. Press either the YES or NO
button(s) and either YES or NO will
be displayed; then press the NEXT
button.
c. Use Rain Sensor: YES will begin to
blink; press either the YES or NO
button(s) and either YES or NO will
be displayed; then press the NEXT
button.
d.
G
c.
9
b.
I
I
a.
H
ADV CONTROLLER SETUP
ETo Adjust Factor
Zone To Zone Delay
Suspend Watering When
Rain Reaches
-OR- Temp Below
90%
4 Seconds
0.10in
35°F
NEXTBACK
Use Master Valve YES
Use Rain Gauge YES
NEXTBACK
ADVANCED SETUP
Zone 6
Use Master Valve NO
Use Rain Gauge YES
NEXTBACK NO YES
ADVANCED SETUP
Zone 6
Use Master Valve NO
Use Rain Gauge NO
NEXTBACK NO YES
ADVANCED SETUP
Zone 6
SPECIAL FEATURES
Event Days Off
Adv. Controller Setup
Advanced Zone Setup
SELECT
Save Contractor Dflts
Set Units
Short Circuit Test
