Rain Bird ESP-SMT User Manual

ESP-SMT Smart Modular Control System
82
8. Determine the Eciency Rating - Chose an
eciency rating based on your visual observation
of system condition and operating pressure at the
nozzle from the Table below:
Poor
Performance
Average
Performance
Good
Performance
Sprays
Rotors
Bubblers
Drip
Rotary Nozzle
60%
70%
60%
80%
70%
50%
55%
50%
70%
55%
70%
80%
70%
90%
80%
Sprinkler Type
Example: Zone 1 Sprinkler Type is a Rotor and the zone
operating condition is average, so the sprinkler eciency
value is 70% based on information in the table above.
9. Determine the Net Application Rate - The ESP-
SMT controller will automatically calculate the Net
Application Rate for the zone in which you entered
the Precipitation Rate and Eciency.
Example: Precipitation Rate = 0.44 inches per hour
Eciency = 70%
Net Application Rate for Zone 1 is 0.31 inch/hour
(0.44 X 70%) = 0.31 inches per hour
Zone System Audit Method (most accurate)
1. Place a series of catchment devices (that are the
same size & shape) throughout the area that the
zone is irrigating.
2. Turn on the zone and run for at least 10 minutes to
collect water in the catchment device.
3. The amount of water collected in each catchment
device is measured and analyzed to determine the
Distribution Uniformity (DU).
Information on how to perform an Irrigation
System Audit correctly is available on the Irrigation
Association web site at www.irrigation.org
