ESP-SMT Smart Modular Control System
43
F
The NEXT IRRIGATION EST. screen
will appear displaying the next
estimated cycle and run times
for Zones 1 thru Zone 5; press
the MORE button and the same
information for Zones 6 thru Zone
10 will appear.
G
The NEXT IRRIGATION EST. screen
will appear displaying the next
estimated cycle and run times
for Zones 6 thru Zone 10; press
the MORE button and the same
information for Zone 11 thru Zone
13 will appear.
H
The NEXT IRRIGATION EST. screen
will appear displaying the next
estimated cycle and run times
for Zones 11 thru Zone 13; press
the DONE button to return to the
CONTROLLER REVIEW screen.
!
NOTE: If the measured rainfall
appears to be significantly less
than the actual rainfall, see the
trouble-shooting section in the
Appendix.
Weather Data Review
Allows you to review the current
temperature and the measured rainfall
over the past 24 hours based on the
information communicated to the ESP-
SMT controller from the SMT Weather
Sensor.
I
If you would like to review the
current temperature and the rainfall
that has occurred in the last 24 hours
as measured by the SMT Weather
Sensor; press the UP or DOWN
button(s) until Weather Data is
blinking on the display; press the
SELECT button.
J
The WEATHER DATA screen will
appear displaying the current
temperature, as well as the amount
of rainfall measured in the last 24
hours (- or + 1 hour) by the ESP-SMT
sensor.
H
G
F
I
J
NEXT IRRIGATION EST.
Zone Date Minutes
1 15 Dec
13 Dec
17 Dec
OFF
13 Dec
21
7
2
3
4
5
MOREBACK
Default
Default
NEXT IRRIGATION EST.
Zone Date Minutes
6
7
8
9
10
16 Dec
20 Dec
OFF
19 Dec
17 Dec
Default
120
5
7
MOREBACK
NEXT IRRIGATION EST.
Zone Date Minutes
15 Dec
OFF
OFF
28
11
12
13
DONEBACK
CONTROLLER REVIEW
Controller Settings
Zone Settings
Next Irrigation Est.
Weather Data
Weather Log
Event Log
SELECT
WEATHER DATA
Current Temp: 72 ºF
Rain in Last
24 Hours: 1.24 in
BACK
