Raymarine A65 User Manual

7.6Manuallydisplayingthepilot
controldialogbox
YoucanalsoopenthePilotControldialogatany
timefromthehomescreenorchartapplication.
1.Fromthehomescreen:
i.SelectSet-up.
ii.SelectPilotControls.
2.Fromthechartapplication:
i.SelectMenu.
ii.SelectNavigate.
iii.SelectPilotsControls.
7.7PilotControldialog
ThePilotControldialogcanbeusedtocontrol
autopilotfunctions.
PilotControldialog(standby)
TheexamplebelowshowsthePilotControldialog
optionswhenthedialogisopenedfromamenuor
usingadedicatedphysicalPilotbutton.
SelectingAutowillengagetheautopilotand
maintainthecurrentheading.
PilotControldialog(Auto)
TheexamplebelowshowsthePilotControldialog
optionswhenAuto(lockedheading)hasbeen
engaged.
D12882-1
1
2
3
4
5 6
8
7
Description
1
PilotStatus—Currentpilotmode.
2
LeftArrow—Decreaselockedheadingangle.
3
Rudderbar—Indicatesthepositionoftherudder.
4
STANDBY—Disengagestheautopilotandreturnsto
manualvesselcontrol.
5
Currentlockedheading.
6Track—EngagestheautopilotinTrackmodeand
automaticallysteersyourvesseltoatargetwaypointor
alongarouteplottedonyourchartplotter.
7
RightArrow—Increaselockedheadingangle.
8
Close—ClosesthePilotControldialog.
PilotControldialog(Startingnavigation)
TheexamplebelowshowsthePilotControldialog
optionswhenGotoCursor,GotoWaypointor
FollowRoutehasbeenselected.
D12206-2
1
2
3
4
5 6
9
8
7
Autopilotcontrol
87
