4.4 SeaTalk
ng
connection
The unit connects as part of a SeaTalk
ng
network.
Example: SeaTalk
ng
Evolution system with iTC-5
12 V dc

SeaTalk
ng
SeaTalk
ng
D13026-1
2
7
1
3
4 5
6
8
9 10 11
1
ACU unit
2 2 x Instruments
3
p70 / p70R Pilot controller
4 Vessel’s 12 V dc power supply
5
EV unit
6
SeaTalk
ng
5–way connector
7
Rudder reference transducer
8
iTC-5 converter
9 Depth transducer
10 Wind transducer
11
Speed transducer
Note: In the above example if an ACU-100 was
used, the SeaTalk
ng
network would require a
dedicated 12 V dc power supply because the
ACU-100 does not supply power to the SeaTalk
ng
network.
Example: SeaTalk
ng
SPX system with transducer
pods
SMARTPILOT
12 V dc
SeaTalk
ng
SeaTalk
ng
D12099-2
2
7 8
1
3
4
6 6 6
5
9 10 11
Item Description
1
SPX (supplying 12V to SeaTalk
ng
network.)
2 2 x Instruments
3
p70 / p70R Pilot controller
4 Vessel’s 12 V dc power supply
5
SeaTalk
ng
5–way connectors with terminators
6 Transducer pods
7
Rudder reference transducer
8. Fluxgate compass
Cables and connections 25
