12.1 Set up menu
The set up menu provides a range of tools and
settings to congure the pilot controller.
Menu item Description Options
Autopilot
Calibration
Pilot
commissioning /
calibration settings
SeaTalk
ng
• Vessel settings.
• Drive settings.
• Sailboat
settings.
• Commissioning.
SeaTalk
• User settings.
• Dealer settings.
• Seatrial
calibration.
User Preferences Set user
preferences such
as: Time &
Date, Units of
measurement,
Language, Vessel
type, Vessel
details, and
Variation.
User preferences
menu.
System Set-up Set system
grouping, display
and system color
and brightness,
Multiple data
sources and about
system set up.
System set up
menu.
Simulator
Enables or
disables simulator
mode, which
allows you to
practice operating
your instrument
display without
any data from any
other external unit.
• On
• Off
Factory Reset Delete user
settings and
Restore unit to
factory default
settings.
• Yes
• No
Diagnostics
Information About
the display and
system and key
beep on / off
setting.
• Yes
• No
Set-up Wizard
Launch the initial
set-up wizard.
• Language
• Vessel hull type
• Welcome page
12.2 Autopilot calibration menu
The Autopilot Calibration menu options are
determined by the connected autopilot system.
Note: Not all options are available when
Calibration Lock is turned On.
Note:
• (1) — SPX and SeaTalk SmartPilots only.
• (2) — Evolution autopilots only.
Menu Options
Vessel Settings
• Vessel Hull Type
• Drive Type
• Cruise Speed
(1)
• Compass Offset
• Latitude Compass Damping
(1)
• Calibration Lock
Drive Settings • Rudder Gain
(1)
• Response Level
(1)
• Counter Rudder
(1)
• Rudder Damping
• Auto Trim
(1)
• Auto Turn
• Power Steer
(2)
• Reverse Rudder Ref.
• Off Course Alarm
(1)
• Turn Rate Limit
(1)
• Motor Phasing
• Rudder Limit
• Rudder Offset
(2)
• Hard Over Time
82
p70 / p70R
