Commissioning menu
Commissioning menu options are dependant on connected autopilot system.
Menu option Description Evolution autopilots
SeaTalk and SPX
SmartPilots
Dockside Wizard Initiates the Dockside wizard
process.
Yes Yes
Sea Trial Wizard Initiates the Sea Trial wizard
process.
N/A
Yes
Motor phasing Initiates the motor phasing
(drive check) wizard
N/A
Yes
Swing Compass
Initiates the swing compass
wizard
N/A
Yes
Auto Learn Initiates the Auto Learn
process
N/A
Yes
Align Compass GPS
(1)
Initiates the align compass to
GPS heading wizard
Yes Yes
Align Compass
(1)
Manual adjustment of the
compass offset
• -10° to 10° • -179° to 180°
Pilot Factory Reset Resets the autopilots course
computer to factory default
settings.
• Yes
• No
• Yes
• No
Restart Compass
Restarts the compass • Yes
• Cancel
N/A
Compass Lock Locks the compass from
performing further automatic
linearization.
• On
• Off
N/A
Debug Level
(1)
Sets the debug value for
troubleshooting purposes.
The recommended Debug
setting is 7.
Note: The Debug
level should only be set
temporarily, usually when
requested by Technical
Support as part of a
troubleshooting sea trial.
• 0 — 63
N/A
ACU Debug Level
(1)
Sets the debug value for
troubleshooting purposes.
The recommended Debug
setting is 7.
Note: The Debug
level should only be set
temporarily, usually when
requested by Technical
Support as part of a
troubleshooting sea trial.
• 0 — 127
N/A
Note:
(1)
Option not available when Calibration Lock is turned On.
User Settings
When connected to a SeaTalk autopilot system a
User settings menu will be available.
The User settings menu can be accessed from:
Main Menu > Set up > Autopilot calibration >
User settings. Once entered the user settings
menu will cycle through all available options. These
options shall be available to users when calibration
lock is turned on.
Set up menu options
89
