14 June, 2002 SPECIAL TOOLS AND LUBRICANTS
2-1
Preventive
Maintenance
2. PREVENTIVE MAINTENANCE
2.1 SPECIAL TOOLS AND LUBRICANTS
• Flash memory card -4M (P/N: N8036701)
• Flash/SRAM data copy tool (P/N: A1939353/H5159100)
2.2 PM TABLE
Scanner/ADF
Item 30K 60K 120K 180K Notes
Pick-Up Roller Ass’y
(Including Feed Roller)
R (user) R (user) R (user) R (user) ADF Maintenance Kit
Reverse Roller R (user) R (user) R (user) R (user) ADF Maintenance Kit
Exposure Glass C (user) C (user) C (user) C (user) Soft cloth and water
R0, R1 and R2 Rollers C (user) C (user) C (user) C (user) Soft cloth and water
Pressure Roller C (user) C (user) C (user) C (user) Soft cloth and water
White Shading Plate C (user) C (user) C (user) C (user) Soft cloth and water
Printer
Item 30K 60K 120 180K Notes
Fusing Unit - R (user) R (user) R (user)
Fusing Maintenance
Kit
Transfer Roller - R (user) R (user) R (user)
Fusing Maintenance
Kit
Paper Feed Roller - - - R (FST)
Registration Roller - C (user) C (user) C (user) Soft cloth and water
Paper Feed Unit (Optional)
Item 30K 60K 120K 180K Notes
Feed Roller - - - R (FST)
FST: Field Service Technician
C: Clean, R: Replace
NOTE: After replacing a maintenance kit, make sure to reset the appropriate PM
counter through the Key Operator Tools menu (User Tools – Key Operator
Tools – System Settings – Reset PM Counter).

Ricoh 5510L Specifications

General

Brand	Ricoh
Model	5510L
Category	Fax Machine
Language	English
